To determine the specific gravity of given sample of fine aggregates (river sand and beach sand) using Pycnometer.
Pycnometer, Weighing scale, Glass rod etc.
Description Specific Gravity of Fine Aggregate is the ratio of mass of a given volume of fine aggregate to the mass of an equal volume of water.Take empty weight of pycnometer along with its cap using weighing scale.
Weight of empty pycnometer(W1)= _____ g
_____
Choose the type of sand
Open the cap to fill one third of pycnometer with fine aggregate and weigh the pycnometer with aggregate.
Weight of pycnometer + 1/3rd of fine aggregate(W2)= _____g
_____
Add water to pycnometer upto the brim level and shake it well to remove air bubbles. Then weigh it using weighing scale.
Weight of pycnometer + 1/3rd of fine aggregate +water (W3)=_____ g
_____
Empty the pycnometer and fill water upto brim. Weigh the pycnometer.
Weight of flask+water (W5) = _____ g
_____
Weight of empty pycnometer(W1)= _____ g
Weight of pycnometer + 1/3rd of fine aggregate(W2)= _____g
Weight of pycnometer + 1/3rd of fine aggregate +water (W3) = _____ g
Weight of pycnometer + water(W4) = _____ g
✔
✘
Specific gravity of fine aggregate = ( W2-W1 )⁄( W4-W1 )-( W3-W2 )Specific gravity of fine aggregate =
✔
✘
Specific gravity of fine aggregate = ( W2-W1 )⁄( W4-W1 )-( W3-W2 )Specific gravity of fine aggregate =
Trial | Specifc gravity of fine aggregate | Average specific gravity |
1 | ||
2 |
✔
What is the range of specific gravity of river sand?
Less than 2.6 2.6-2.85 Greater than 2.85What is the range of specific gravity of beach sand?
Less than 2.4 2.4-2.6 Greater than 2.6Trial =
